Specifications & Details • Connection thread (in/out) : 3/8″ • Intake pressure min –max in bar : 2 – 8 • Water temperature min – max in °C : 4 – 40 • Ambient temperature min – max in °C : 4 – 60 • Total height without bracket (A) in mm : 500 • Total height with bracket (B) in mm : 530 • Connection height (C) in mm : 450 • Distance from floor (D) in mm : 65 • Installed length (E) in mm : 125 • Filter cartridges Ø (F) in mm : 145 • Weight in kg, approx: 4.0 • Order no Installation set:FS28P01A00 • Order no. Filter cartridge : FS28P00A00
