Power Supply : 220 V – 400 V

Nominal Power : 3450 W

Group Head : 58 mm

Boiler ( Liter ) : 11

Pump : Rotary*

Colour : Stainless Steel AISI 304 body

Widht (mm) : 824

Depth (mm) : 565

Height (mm) : 525

Weight ( Kg ) : 67

Display : PID Touch screen

Capacity ( Cup / Day ) : 250 – 300 cup / day

Professional Machine with control box manages the coffee dosing programmed by the user, you may programme 4 different coffee doses for each group. Arcadia is the first professional espresso machine able to prepare coffee with the drip brewing method, with the same brewing head used to brew an espresso.

Main Technical Features:

Multi-boiler system. The ultimate production capacity in the right moment: Victoria system is equipped with 3 independent boilers with dedicated On/Off switch: left steam output boiler, right steam and hot water output boiler, and each brew unit has its own coffee boiler, a special program connect the 2 main steam boilers in order to get a non-stop steam generator.

TFT display programming. The programming is done through state of the art touch displays, that by a dedicated human interface allows to easily program the machine parameters, using pre-set profiles or giving the maximum customisation opportunity.

Patented brewing profile system. Using BEZZERA pressure profile patent is possible to brew drip coffee and herbal infusion with dedicated low pressure programs. The double boiler hydraulic system is drawn by a Volumetric dosage that allows to set pressure profiles from 3 to 11 bar to maximise the coffee extraction experience. Using BEZZERA pressure profile patent is possible to brew drip coffee and herbal infusion with dedicated low pressure programs.

Automatic water regeneration. In order to keep ph and water quality under control the automatic regeneration system of Water and Steam boilers allows to schedule a daily recycling.

Coffee temperature control. The new coffee extraction temperature control system by PID thermostat, allows an accurate programming of the coffee temperature in the cup, thanks to the hydraulic circuit thermo stability the exaltation of the aromas of each type of coffee is granted.

Additional Information:

Boiler Capacity: 2x6 + 2x1L
