2 Group
Technical Data 2 Groups
Voltage (V) 220/240 1N, 380/415 3N
Power Input (KW) 7.7
Steam Boiler Capacity (lt) 8
Boiler Resistance Power (kW) 3.8
Pump Power (kW) 0.15
Preheating boiler capacity (lt) 2.8
Preheating boiler resistance power (kW) 1.6
Cup-heater Power (KW) 0.2
Units boiler capacity (lt) 1.0
Units boiler resistance power (kW) 1.6
Net weight (Ib/kg) 200/91
Weight (with shipping crate) (lb/kg) 304/138
Width (inches/mm) 29.3/745
Depth (inches/mm) 25.2/640
Weight (inches/mm ) 17.3/440
3 Group
Technical Data 3 Groups
Voltage (V) 8.75
Power Input (KW) 10
Steam Boiler Capacity (lt) 3.8
Boiler Resistance Power (kW) 3.8
Pump Power (kW) 0.15
Preheating boiler capacity (lt) 2.8
Preheating boiler resistance power (kW) 1.6
Cup-heater Power (KW) 0.25
Units boiler capacity (lt) 2.4
Units boiler resistance power (kW) 2.4
Net weight (Ib/kg) 249/113
Weight (with shipping crate) (lb/kg) 373/169.5
Width (inches/mm) 40.9/1040
Depth (inches/mm) 25.2/640
Weight (inches/mm ) 17.3/440
